2.5 Inch Alloy Steel Wireline Tool String Jar For Upward Jarring

2.5 Inch Alloy Steel Wireline Tool String Jar For Upward Jarring

Wireline Spring Jar Wireline Tool String
I. introduction
A wireline spring jar is designed to provide upward jarring during heavy duty fishing operation. It can guarantee the faultless operation with least maintenance.
ii. Structure characteristics
When The wireline spring jar is closed, the slip on the jar stem will stretch and clamp on the extension rod under the function of spring. When lifting, the jar stem will drive the slip to pull the extension rod and squeeze the disc spring to reserve energy. When the jar stem runs for some stroke, the slip will be squeezed by the pup joint and disconnect with the extension rod. Then theenergy of disc spring will release immediately to finish the jarring effect.

III. General Technical Parameters

Note: More customized parts are available upon request.
IV.Matters needing attention
1. After several times of use, the lock block, spring and slip should be checked for damage and replaced in time;
2. The spring jar only has multiple upward jar functions and cannot be used for downward jar.
3. Spring jar is not suitable for operation in Wells with large sand content, so as to avoid sand chips entering the jar and causing failure of the jar.
Welcome to contact us at any time.


◆About Baoji RuiXin Slickline Tools
Baoji Ruixin Energy Equipment Co., Ltd. was established in 2012. It is an IS0: 9001-2015 and API Q1 system certified technology research and development organization specializing in the design and manufacture of steel wire, cable and coiled tubing tools. With strong new product research and development capabilities, it has obtained 12 national utility model patent certificates and 1 invention patent certificate. Undertook two prefecture-level and provincial-level scientific research projects. Our products include wireline wireline wellhead blowout prevention equipment, wireline downhole tools and coiled tubing downhole tools. At present, we have provided professional equipment and technical support to more than 50 oilfield service companies in various regions at home and abroad.
◆Strict quality control system
Steel wire working tools are certified by API, and all manufacturing are strictly in accordance with API system, including quality control management, environmental management and occupational health and safety management. For each wire working tool and each part, we have achieved traceability from raw materials, production process to product shipment.
◆Hard work, after-sales service
On-site technical guidance exchanges with each other. Our sales and technical personnel communicated well with front-line engineers and technical experts on the job site, and solved technical problems such as material selection, sealing structure optimization, and accident handling in complex environments. And carried out many technical exchanges and friendly cooperation. We have done a good job of product after-sales service for customers, and we provide customers with more satisfactory services. We would like to thank more and more customers for their support and trust. In the future, we will do better.

2.5 Inch Wireline Tool String Jar

Alloy Steel Wireline Spring Jar

2.5 Inch Alloy Steel Wireline Tool String Jar For Upward Jarring Images
